AgieCharmilles CUT 1000 Series

Designed for outstanding accuracy
GF Machining Solutions’ CUT 1000 series, specifically designed to meet micro dimensions demands, offers unique features in terms of precision and productivity, and perfect predictability and repeatability of machining results.

Excellence in results

Deliver the highest precision parts with CUT 1000 series' X-treme precision version. The innovative mechanical structure of the CUT 1000 and a consistent separation of the sources of heat from the EDM area, kept constantly under water, as well as an optimal water circuit ensure the prerequisites for outstanding results.

Process automation

Automate your productivity and use large wire for fast, cost-effective roughing, while machining with thin wire to cut fine radii at the best precision. Control the part from design to quality control with a complete integrated solution.

Flexibility and efficiency

Simplify your manufacturing process with the ultra-flexible machine and HMI concept and reduce delivery time to your customers. Increase reactivity and take urgent jobs or change your day and night strategies on the fly.

CUT 1000 / CUT 1000 OilTech

Please accept all cookies to view the external content.

AgieCharmilles CUT 1000
AgieCharmilles CUT 1000
AgieCharmilles CUT 1000
AgieCharmilles CUT 1000
1/

2 x 8 kg

Numbers of wires available with Automatic Wire Changer. The CUT 1000 also has optimal capacity on the two wire circuits.

0.020 mm

High accuracy in the inner radii. Exactness in machining the small details with provision for machining inner radii down to 0.020 mm.

Higher design flexibility

Higher design flexibility

Achieve ultra fine radius over large heights. Increase your design flexibility and forget about manual guide change when using different wire diameters.

Miniaturize further

Miniaturize further

Obtain the best accuracy on micro-electronics. An easy fine wire management is now at your fingerprints.

Achieve highest accuracy in any condition

Achieve highest accuracy in any condition.

Ensure an absolutely constant temperature of the water in the work tank. The water is cooled in the main dielectric tank before recirculation. The water level is adjusted automatically to the workpiece height by raising and lowering the filled work tank.

Total accuracy and repeatability

Total accuracy and repeatability

Due to an exclusive machine design concept, the CUT 1000 meets highly demanding requirements in terms of positioning accuracy. These results are possible thanks to a monoblock framework with separated X and Y axes.

Excelence in surface finish

Excelence in surface finish

Get the best surface finish even on water conitions and forget about post-process polishing.

CUT 1000 OilTech

CUT 1000 series OilTech version are designed for the excellence in surface integrity and surface finish. Reduce the number of cuts needed to achieve the best surface finish.

No corrosion

Parts machined on the CUT 1000 OilTech have exceptional surface quality. There is no coloration due to oxidation or redeposit of materials suspended in the dielectric.

Oil machining for ultimate results

Get the perfect solution for luxury watches.The machined parts are sound and without defect, ready to be used, aesthetically perfect, and of exceptional quality, meeting the very high demands of the watch making industry.

CUT 1000 OilTech

Please accept all cookies to view the external content.

AgieCharmilles CUT 1000 OilTech
AgieCharmilles CUT 1000 OilTech
AgieCharmilles CUT 1000 OilTech
AgieCharmilles CUT 1000 OilTech
1/
The world of micro dimensions

The world of micro dimensions

In the manufacture of high-precision stamping tools and in the production of micro components, best contour accuracy, finest surface finish and highest repeatability are absolute musts.

Surface quality at the highest level

Surface quality at the highest level

The CUT 1000 OilTech uses an inert dielectric (oil), making it possible to produce parts with unsurpassed surface quality, even if this includes long-term immersion in the dielectric.

Specifications

CUT 1000

Main Specifications

Main Specifications
Travel X, Y, Z

220 x 160 x 100 mm

8.66 x 6.3 x 3.93
Min. surface roughness RA 0.05 μm
Max. taper angle / height

± 3°/80 mm

± 3°/3.14 in
Max. workpiece dimensions *

300 x 200 x 80 mm

11.81 x 7.87 x 3.14 in
Max. workpiece weight

35 kg

77 lbs

Workpiece

Workpiece
Travel U, V

± 40 mm

± 1.57 in
Wire diameters

0.07 - 0.20 (0.02-0.05 optional) mm

0.003 - 0.008 (0.0008 - 0.002 optional) in
Max. wire spool weight 2x8 kg

* Width x depth x height

CUT 1000 Oiltech

Main Specifications

Main Specifications
Travel X, Y, Z

220 x 160 x 100 mm

8.66 x 6.3 x 3.93
Min. surface roughness RA 0.05 μm
Max. taper angle / height

± 3°/80 mm

± 3°/3.14 in
Max. workpiece dimensions *

300 x 200 x 80 mm

11.81 x 7.87 x 3.14 in
Max. workpiece weight

35 kg

77 lbs

Workpiece

Workpiece
Travel U, V

± 40 mm

± 1.57 in
Wire diameters

0.07 - 0.20 (0.02-0.05 optional) mm

0.003 - 0.008 (0.0008 - 0.002 optional) in
Max. wire spool weight 2x8 kg

* Width x depth x height
