Mikron MILL E 500/700 U

Unleash your full potential
The range of solutions is a second-generation successor to the HEM U range. It brings greater machining capacity and better machining performance to a more robust machine base. With the large swivel range from -65° to + 120° and the ability to load heavy parts up to 450 kg onto the tilting, swiveling table, these solutions U allows users to manufacture a wider range of parts and tools than any other machine currently on the market. It is based on a stiff and stable C-frame construction made out of cast iron. Thanks to large guideways, a double side-supported rotary table and an optimum chip removal rate, this machine delivers quality on parts and reliable operations. Whether you are a job shop or a part producer, these machines are the right solutions to help you tackle the many different requirements coming from the automotive, energy and power generation, and general mechanics industries.

Unleash your business

Unleash your business with these solutions for 3+2 and full simultaneous Milling. Save time, costs and operator error—whatever your machine choice.

Unleash your best

Produce with 100% quality and unleash your best with this affordable, high-efficiency solution.

MILL E 500 U - MILL E 700 U

Please accept all cookies to view the external content.

Milling machine - 5 axis - Mikron MILL E U Series MILL E 500 U
Milling machine - 5 axis - Mikron MILL E U Series MILL E 700 U
1/

+ 10% heavy-duty, precise and dynamic Milling

450 kg load on the table Stepwise adjustment of the dynamic. Strong motor Spindle with 120 Nm

24/7 billable autonomy

Integrated Automation with GF Machining Solutions' WPC 10. Various pallets (Dynafix/Delphin) are available as standard. This solution comes prepared for third-party automation with robot interface and rotary joint trough table. The machine's autonomy can be extended even further thanks to the Automatic Tool Changer (ATC) with up to 215 positions.

100% quality, reliability and billable performance

Well-known and proven components, Swiss-made Spindle. Torque-driven and double-supported rotary table. GF Machining Solutions Customer Services' rConnect.

+ 50% more capacity

Profit from a stiff and stable machine design thanks to big 45 mm guideways, 40 mm diameter ball screw to support axes' movements and additional cast iron of 250 kg to strengthen machine behavior.

Flexible and efficient

Flexible and efficient

Airbag shooting device
Leverage flexibility with many different Milling processes with tools from ø 4 up to 40 mm. Do roughing with high removal rate or mill perfect surface finishes.

Surgical support device

Produce better and cheaper

Surgical support device
Reduce operating time and costs. Thanks to the rigid machine construction and the powerful 20,000 rpm motor Spindle, process time can be improved and production costs can be reduced.

Flip over but stay accurate and stable

Flip over but stay accurate and stable

Concentricity challenge
Thanks to the torque-driven rotary table, positioning accuracy on five-sided parts is ensured and repeatability within 10 µm is secured. General mechanics industry.

Specifications

MILL E 500 U

Main Specifications

Main Specifications
Travel X, Y, Z 500 x 450 x 400 mm
Feed rate X/Y/Z 30 m/min
Swivelling range -65°
+120°
Rotary range n x 360°
Feed rate swivel 17 (3+2)
32 (5X simultaneous with DD) rpm
Feed rate rotary 28 (3+2)
112 (5X simultaneous with DD) rpm
Working table T-slot table Ø500 mm
System 3R Dynafix 350x350 / Erowa UPC 320x320 mm
System 3R Delphin 400x400 / Erowa MTS 400x400 mm
Table load 300 / 500 (5X simultaneous with DD) kg
Working spindle 20'000 rpm - HSK-A63
12'000 rpm - ISO & BT40
Tool magazine 30 / 60 / Tool Tower 120 / 170 / 215 pockets
Automation Pallet magazine 7 Dynafix / UPC
Pallet magazine 5 Delphin / MTS
System 3R Workpartner 1+, Transformer WorkMaster & Transformer 6-axis
Controll unit TNC 640 (Heidenhain)
Fanuc 0i-MD

MILL E 700 U

Main Specifications

Main Specifications
Travel X, Y, Z 700 x 600 x 500 mm
Feed rate X/Y/Z 30 m/min
Swivelling range -65°
+120°
Rotary range n x 360°
Feed rate swivel 17 (3+2)
32 (5X simultaneous with DD) rpm
Feed rate rotary 28 (3+2)
112 (5X simultaneous with DD) rpm
Working table T-slot table Ø630 mm
System 3R Dynafix 350x350 / Erowa UPC 320x320 mm
System 3R Delphin 400x400 / Erowa MTS 400x400 mm
Table load 300 / 500 (5X simultaneous with DD) kg
Working spindle 20'000 rpm - HSK-A63
12'000 rpm - ISO & BT40
Tool magazine 30 / 60 / Tool Tower 120 / 170 / 215 pockets
Automation Pallet magazine 7 Dynafix / UPC
Pallet magazine 5 Delphin / MTS
System 3R Workpartner 1+, Transformer WorkMaster & Transformer 6-axis
Controll unit TNC 640 (Heidenhain)
Fanuc 0i-MD

Discover our videos

Please accept all cookies to view the youtube video content.

Download brochure
